Lovibond E-Comparator EC 2000 Pt-Co Electronic Color Measurement (Hazen / APHA Scale)
Precision electronic color measurement instrument replacing subjective visual inspection for Pt-Co / Hazen / APHA color scale according to ASTM D1209, featuring touchscreen interface and USB connectivity.
Technical Specifications
| Internal Storage | > 20,000 readings |
|---|---|
| International Standard | ASTM D1209 (Pt-Co / Hazen / APHA Color Scale)` |
| Measuring Range | 2 – 500 Pt-Co / Hazen / APHA |
| Interface / Connectivity | USB 2.0 Micro-B Port for Windows PC Connection |
| Repeatability | ± 3% + 1 Pt-Co Unit |
| Optical Detectors | Tristimulus Detectors (Reference & Sample) |
Full Product Description
The Lovibond® E-Comparator EC 2000 Pt-Co provides an intuitive way to transition from subjective visual color comparison to accurate, objective electronic colorimetry while retaining the on-screen visual confirmation of the sample color view. Engineered specifically for clear liquid quality control, petrochemical solvents, treated water, and industrial resins, it measures the Platinum-Cobalt (Pt-Co / Hazen / APHA) color scale in strict accordance with ASTM D1209.
Key Technical Advantages:
• Objective Electronic Accuracy: Eliminates operator subjectivity utilizing precision tristimulus reference and sample detectors powered by an ultra-long-life White LED light source (25-year service life).
• Modern 3.5" Touchscreen Interface: Features a 3.5" resistive color display (320 x 240 resolution, 24-bit True Colour) with intuitive multi-lingual menus.
• Extensive Data Logging: Stores over 20,000 readings complete with timestamps and user-defined project IDs.
• Seamless PC Connectivity: Integrated Micro-USB 2.0 interface enables direct export to Windows® software packages for audit-ready compliance reporting.
• Custom Tolerance Configuration: Users can define specific upper and lower color acceptance limits for automated pass/fail quality screening.
Traceable Validation Standards:
Supplied with traceable liquid reference standards (Pt-Co 5, 10, 15, 30, 50, 100) and optical glass standard conformity filters guaranteeing certified calibration.
Key Technical Advantages:
• Objective Electronic Accuracy: Eliminates operator subjectivity utilizing precision tristimulus reference and sample detectors powered by an ultra-long-life White LED light source (25-year service life).
• Modern 3.5" Touchscreen Interface: Features a 3.5" resistive color display (320 x 240 resolution, 24-bit True Colour) with intuitive multi-lingual menus.
• Extensive Data Logging: Stores over 20,000 readings complete with timestamps and user-defined project IDs.
• Seamless PC Connectivity: Integrated Micro-USB 2.0 interface enables direct export to Windows® software packages for audit-ready compliance reporting.
• Custom Tolerance Configuration: Users can define specific upper and lower color acceptance limits for automated pass/fail quality screening.
Traceable Validation Standards:
Supplied with traceable liquid reference standards (Pt-Co 5, 10, 15, 30, 50, 100) and optical glass standard conformity filters guaranteeing certified calibration.
