IKA Magnetic Stirrers with Heating (RCT 5 digital & C-MAG HS Series)
Heated magnetic stirrers meeting the highest safety standards (DIN IEC EN), heating power up to 1,500 W, and chemical-resistant glass ceramic plates.
Technical Specifications
| Safety Standards | CE Certified, DIN IEC EN 61010-1, 61010-2-010, 61010-2-051, 61326-1 |
|---|---|
| Max. Stirring Quantity (H2O) | 5 L (HS 4) / 10 L (HS 7) / 15 L (HS 10) / 20 L (RCT 5 / HS 7 control) |
| Speed Range | 50 – 1.500 rpm (RCT 5 / HS 7 control) / 100 – 1.500 rpm (C-MAG HS) |
| Heat Output | 850 W (RCT 5) / 1.000 W (HS 7) / 1.500 W (HS 10) |
| Max. Heating Temperature | RT + self heating s/d 310°C (RCT 5) / 50 – 500°C (Seri C-MAG) |
| Set-up Plate Material | Ceramic-Coated Aluminum (RCT 5) / Glass Ceramic (C-MAG Series) |
| Protection Class | IP 42 (RCT 5 digital) / IP 21 (C-MAG HS Series) |
Full Product Description
Safety is the highest priority for IKA. Our heated magnetic stirrers meet the highest safety standards to protect all users in the laboratory: They have CE certifications and meet all requirements described in standards such as DIN IEC EN 61010-1, DIN IEC EN 61010-2-010, DIN EN IEC 61010-2-051, and DIN IEC EN 61326-1.
Product Range Highlights:
1. IKA RCT 5 digital:
- Powerful 850 W heating output reaching up to 310°C with 20 L stirring capacity.
- Ceramic-coated aluminum top plate (137 x 137 mm) providing uniform heat transfer and scratch resistance.
- Adjustable independent safety circuits and IP 42 protection.
2. IKA C-MAG HS 7 control & C-MAG HS Series (4, 7, 10):
- Solid, seamless glass ceramic top plates offering exceptional resistance to aggressive chemicals.
- High-temperature heating up to 500°C with heat outputs of 250 W (HS 4), 1,000 W (HS 7), and 1,500 W (HS 10).
- Available in Digital (integrated PT 1000 temperature sensor connectivity) and Basic models (compatible with ETS-D5 electronic contact thermometer).
